Version 0.5.6 (fix bugs from 0.5.5)

screenshot news sorting
Figure 1. Column headers show sorting directions
How to keep the context when clicking on a table
def showPart(PlmFreeCadPart part, Long partVersion, Boolean isHistory) {(1)
    taackUiService.show(
            plmFreeCadUiService.buildFreeCadPartBlockShow(
                    part, partVersion, false, isHistory),               (2)
            buildMenu(),
            "isHistory")                                                (3)
}
1 isHistory is an action parameter
2 isHistory is used when drawing the block; we need to retransmit it to draw the exact same block layout, by keeping the context
3 isHistory key is passed as the last taackUiService.show argument. You can put many keys to keep.

Version 0.5.4

Version 0.5.3

  • Fix form checkbox

  • Allow alias in TQL for formula columns

  • Code cleanup and increment dependency versions

Version 0.5.2

  • JDBC client is now also an AsciidoctorJ extension

  • Add getters to JDBC accessible domain fields

  • Add DSL TQL and TDL (Taack Display Language) for describing how to display queried data (either table or barchart)

  • Restore manual labeling on menus

  • More on diagram DSL (Thanks Chong and ZhenQing)

  • Better customisation

TQL and TDL (Taack Display Language)
select
    u.rawImg,
    u.username,
    u.manager.username
from User u
where u.dateCreated > '2024-01-01' and u.manager.username = 'admin';
--
table rawImg as "Pic", username as "Name", manager as "Manager"
news table
Figure 2. Results

Version 0.5.1

Replacement of TaackPlugin
@PostConstruct
void init() {
    TaackUiEnablerService.securityClosure(
        this.&securityClosure,
        CrewController.&editUser as MC,
        CrewController.&saveUser as MC)
    TaackAppRegisterService.register(
        new TaackApp(
            CrewController.&index as MC,                    (1)
            new String(
                this.class
                    .getResourceAsStream("/crew/crew.svg")  (2)
                    .readAllBytes()
            )
        )
    )
}
1 Entry Point
2 Icon
Replacement of Charts: Diagrams
private static UiDiagramSpecifier d1() {
    new UiDiagramSpecifier().ui {
        bar(["T1", "T2", "T3", "T4"] as List<String>, false, {
            dataset 'Truc1', [1.0, 2.0, 1.0, 4.0]
            dataset 'Truc2', [2.0, 0.1, 1.0, 0.0]
            dataset 'Truc3', [2.0, 0.1, 1.0, 1.0]
        }, DiagramTypeSpec.HeightWidthRadio.ONE)
    }
}
PDF containing diagrams
printableBody {
    diagram(d1(), BlockSpec.Width.HALF)
    diagram(d2(), BlockSpec.Width.HALF)
}
news diagram
Figure 3. Stacked Bar Diagram

Version 0.5.0

Based on Bootstrap

  • Themable

    • Color Scheme from your desktop

    • Adjustable component size

  • Easier to extend

Improved Loading Time

  • Less assets

  • CSS and JS shortened

Main Code Changes

New Layout DSL

  • Same layout for forms and blocks

    • col and row

    • tabs and tab

With for col only

DSL Menu for blocks

  • Menu DSL replace actions

  • No need to use icons

  • Menus are auto-translated

Simpler Code

Leads To :

  • Easier maintenance

  • Easier to contribute

Version 0.4.2

To be released…​ this version should come with some nice changes (breaking some old code sometime)

  • Improve DSL hierarchy

    • hidden fields on top only for readability

    • no redundant parameter passing in form

    • no redundant parameter passing in filter

    • filterField only under section only

    • form top level field only on header

  • hook for form fields to display M2M nicely

  • hook to register typical object filter

  • Improve restore state

  • Fix table grouping / trees with paginate

  • TBD

Version 0.4.1

screenshot news menu 0.4.1
Figure 4. Updated Menus layout
Menus layout code
private UiMenuSpecifier buildMenu(String q = null) {
    new UiMenuSpecifier().ui {
        menu CrewController.&index as MC
        menu CrewController.&listRoles as MC
        menu CrewController.&hierarchy as MC
        menuIcon ActionIcon.CONFIG_USER, this.&editUser as MC
        menuIcon ActionIcon.EXPORT_PDF, this.&downloadBinPdf as MC
        menuSearch this.&search as MethodClosure, q
        menuOptions(SupportedLanguage.fromContext())            (1)
    }
}
1 Language choice is on the right of the searchbar, and other enums can be added
Kotlin JS Debug HowTo
$ cd infra/browser/client                             (1)
$ ./gradlew browserDevelopmentRun                     (2)
$ vi intranet/server/grails-app/conf/application.yml  (3)
# Uncomment line bellow
# client.js.path: 'http://localhost:8080/client.js'

# Then your browser should show Kotlin code !
1 Move to client folder where JS code is generated
2 Launch a server serving client.js and client.js.map …​
3 edit your intranet application.yml file
New Solr DSL Simplification (no more labeling needed)
@PostConstruct
private void init() {
    taackSearchService.registerSolrSpecifier(this,
            new SolrSpecifier(User,
                CrewController.&showUserFromSearch as MethodClosure,
                this.&labeling as MethodClosure, { User u ->
        u ?= new User()
        indexField SolrFieldType.TXT_NO_ACCENT, u.username_
        indexField SolrFieldType.TXT_GENERAL, u.username_
        indexField SolrFieldType.TXT_NO_ACCENT, u.firstName_
        indexField SolrFieldType.TXT_NO_ACCENT, u.lastName_
        indexField SolrFieldType.POINT_STRING, "mainSubsidiary", true, u.subsidiary?.toString()
        indexField SolrFieldType.POINT_STRING, "businessUnit", true, u.businessUnit?.toString()
        indexField SolrFieldType.DATE, 0.5f, true, u.dateCreated_
        indexField SolrFieldType.POINT_STRING, "userCreated", 0.5f, true, u.userCreated?.username
    }))
}

Version 0.4.0

  • No more paginate in tables. See New iterate usage

  • No list, but an iterate taking a closure as parameter, with a builder pattern approach to pass args

  • Menu are auto labeled now (use lang=test in url to translate menus). See New menu code

  • No more isAjax parameter in tables …​ See New rowAction code

  • change rowLink into rowAction [i18n_isAjax]

  • No label needed on rowAction in tables. See New rowAction code

  • No more ajaxBlock required for tables, forms, tableFilters

  • formAction has no more isAjax parameter

  • formAction has no more mandatory i18n parameter

  • form has no more mandatory i18n parameter, i18n is based on current action name

  • block action has no more mandatory i18n parameter, i18n is based on target action

  • block action has no more mandatory isAjax parameter

New iterate usage
iterate(taackFilterService.getBuilder(Role)                     (1)
        .setMaxNumberOfLine(20)                                 (2)
        .setSortOrder(TaackFilter.Order.DESC, u.authority_)     (3)
        .build()) { Role r, Long counter ->
            row {
                rowColumn {
                    rowField r.authority
                    if (hasSelect)
                        rowAction
                            ActionIcon.SELECT * IconStyle.SCALE_DOWN,
                            CrewController.&selectRole as MC
                            r.id                                (4)
                }
            }
        }
1 iterate
2 Specifying max is enough to trigger paginate if more lines
3 Replace the old inefficient pattern to describe initial sort and order
4 No more i18n and isAjax parameter
New menu code
private UiMenuSpecifier buildMenu(String q = null) {
    UiMenuSpecifier m = new UiMenuSpecifier()
    m.ui {
        menu CrewController.&index as MC        (1)
        menu CrewController.&listRoles as MC
        menu CrewController.&hierarchy as MC
        menuSearch this.&search as MethodClosure, q
    }
    m
}
1 No i18n parameter
New rowAction code
if (hasActions) {
    rowColumn {
        rowAction ActionIcon.EDIT * IconStyle.SCALE_DOWN, this.&roleForm as MC, r.id (1)
    }
}
1 No i18n parameter, no last isAjax parameter

Version 0.3.9

No updates since too long, hibernation is coming to an end. This version offer:

  • Grails 6.2.0

  • Groovy 3.0.21

  • Bumping Various deps …​ (See Changelog)
